#MULTITOUCH TAFEL DRIVER#
Mouse Driver – for controlling your mouse cursor.Community Core Vision (CCV) – Windows, Mac, Linux tracking application.Main Finger Tracking Application – needed to track fingers on the MTbiggie.Lights shinning from multiple directions onto the table gives better results than lights from one direction. Even room lighting gives the best results. Below is a video demonstrating the view of what the camera is seeing and tracking.Īll you need is a room with (at least) some infrared light (most lights give off infrared light) a dark room will not work. The webcam sees these shadows and sends the image to the tracking software which tracks the shadows as they move on the touch surface (paper). When you place your fingers on the surface, shadows are created where your fingers are placed. Total Cost: $400 (using low end projector) – $1000+ (using high end projector) – not counting the computer How’s it Work and What Conditions are Necessary? Computer (dual core recommended, but not required).Infrared webcam/camera ( learn to build one yourself here).printer paper, tracing paper, rosco projection material, etc) Piece of clear, flat sturdy material (ie.2 chairs (or anything to prop up the acrylic).To see other methods of building more stable multitouch displays, view the full multitouch display list. The MTbiggie isn’t the most stable and robust setup, but it is the easiest to build.
The MTbiggie is similar to the MTmini, but includes a projected image and infrared webcam (rather than a normal webcam). The MTbiggie uses the “ Front Diffused Illumination” multitouch technique, with ambient infrared light and a DIY infrared webcam.
I created the Multitouch Biggie to show people how something that seems complicated or ‘magical’ can be made simply and at low cost.
It can be used for a variety of purposes including: drawing, OS navigation, games, entertainment and more. A Multitouch Biggie, MTbiggie for short, is a low-cost multitouch table.
